Analog Devices Nano-Power Pushbutton ON/OFF Controller (EU Version)

Description The MAX16150 is an extremely low-power, pushbutton, on/off controller with a switch debouncer and built-in latch. This device accepts a noisy input from a mechanical switch and produces a clean, latched output, as well as a one-shot interrupt output, in response to a switch closure exceeding the debounce period at PB_IN. A switch closure longer than shutdown period at PB_IN results in a longer one-shot interrupt output. The MAX16150 family has two set of devices, one in which a longer switch closure greater than the shutdown period deasserts the latched output, and another in which the latched output stays asserted. The MAX16150 operates from a supply range of 1.3V to 5.5V and consumes less than 20nA of supply current to ensure minimal battery drain in low-power applications, as well as to allow use as a battery “freshness seal”. The robust switch input (PB_IN) accepts up to ±60V levels and is ±15kV ESD-protected for use in harsh environments. The latched output can serve as a logic signal to control a regulator. Also it can serve as a switch to connect the load directly to the power supply. When load current is low, providing 20mA of output current with less than 100mV voltage drop. A separate INT output provides a system interrupt whenever a valid pushbutton signal is detected. An asynchronous CLR input allows an external signal to force the latched output to the off state. The MAX16150 operates over the -40°C to 125°C. The temperature range and is available in a 1mm x 1.5mm, 6-bump wafer-level package (WLP) and a 6-pin, thin SOT23 package. Features ● Low Power • 20nA (max) Standby Current (ISB) ● Debounces Noisy Switches • 50ms and 2s Debounce Timing Options • 8s and 16s Shutdown Timing Periods ● Latched Output Supplies 20mA Load Current with Less Than 100mV Drop ● One-Shot INT Output on Each Switch Closure ● 8ms, 32ms, 64ms, and 128ms INT Timing Options ● Pushbutton Input Handles up to ±60V ● ±15kV HBM ESD Protection ● 6-pin SOT23 and 1mm x 1.5mm, 6-bump WLP Applications ● Portable Instruments ● Handheld Consumer Electronics ● Industrial Equipment ● Disposable Low-Power Electronics Package Includes 1 x Nano-Power Pushbutton ON/OFF Controller
